| PORT SIZE |
G 1 / 8 |
G 1 / 4 |
G 1 / 4 |
G 3 / 8 |
G 1 / 2 |
G 3 / 4 |
| Maximum Supply Pressure |
15 kgf / cm2 |
| Max. Operating Pressure |
9.9 kgf / cm2 |
| Min. Operating Pressure |
N.C. - 1.5 kgf/cm2 |
| Regulating Range |
0.5 ~ 8.5 kgf / cm2 |
| Rate Flow (ANR) |
300 ℓ/min |
300 ℓ/min |
700 ℓ/min |
700 ℓ/min |
1800 ℓ/min |
1800 ℓ/min |
| Oil Mist Removal Efficiency |
MAX 1.0 mg/m3 ( ANR ) ( ≒ 0.8 ppm ) |
| Fluid |
Air |
| Ambient & Media Temperature |
-5 ~ 60 °C ( With no freezing ) |
| Nominal Filtration Rating |
PF: 5 µm / PFM: 1 µm ( 95% filtration efficiency ) |
| Bowl Capacity |
8 cm3 |
8 cm3 |
20 cm3 |
20 cm3 |
45 cm3 |
45 cm3 |
| Bowl Material |
Polycarbonate |
| Weight |
150 g |
150 g |
300 g |
300 g |
600 g |
600 g |
